MCELL Modular Storm Water Tanks

A modular percolation storm water tank designed for filtration, temporary retention and subsequent discharge. It is used in drainage trench application. It is constructed using our proprietary plastic injection moulded panels

MCELL modular storm water tank is a designed for storm water filtration, detention, or retention underground. The panels, a single piece injection moulding, are designed with 40% to 52% void area for water catchment.

Modular Storm Water Tank System

SW Tank Mini

Storm water tank mini
  • Smaller version of our Storm Water Tank
  • Size: 250mm H x 250mm W x 500mm L for drainage trench application.
  • Volume: 0.031m3
  • The strength of the tank can be reinforced with the insertion of PVC pipe inserts (Models 250 and Mini) within the tank, strengthening the walls.
  • Consists of three pairs of differently-sized panels to form the top/bottom, and sides.
  • The panels are assembled together through an interlocking system to construct a modular tank

SW Tank 250

Storm water tank 250mm
  • Size 250mm H x 500mm W x 500mm L for drainage trench application and height make up.
  • Volume: 0.063m3
  • The strength of the tank can be reinforced with the insertion of PVC pipe inserts (Models 250 and Mini) within the tank, strengthening the walls.
  • Consists of three pairs of differently-sized panels to form the top/bottom, and sides.
  • The panels are assembled together through an interlocking system to construct a modular tank

SW Tank 500

Module storm water tanks
  • Size 500mm H x 500mm W x 500mm L for medium size spaces.
  • Volume: 0.125m3
  • The strength of the tank can be reinforced with the insertion of  I-Beam Support (Model 500), within the tank, strengthening the walls.
  • Consists of six identical panels.
  • The panels are assembled together through an interlocking system to construct a modular tank

SW Tank 1000

Storm water tank 1000
  • Size 500mm H x 500mm W x 1000mm L for large area.
  • Volume: 0.25m3
  • The strength of the tank can be reinforced with the insertion of sliders (Model 1000) within the tank, strengthening the walls.
  • Consists of two  differently-sized panels to form the top/bottom, sides, and slider.
  • The panels are assembled together through an interlocking system to construct a modular tank
